INTRODUCTION
| Genset | Genset Model | PLT-20GF | PLTR-20GF |
| Rated Power (kW/kVA) | 20/25 | 20/25 | |
| Standby Power (kW/kVA) | 22/27.5 | 22/27.5 | |
| Rated Current (A) | 36 | 36 | |
| Manufacturer | Pulita Energy | ||
| Gas Engine | Main Engine-Body Make | Cummins | Ricardo |
| Gas Engine Model | PC4L-BG | HT4100D | |
| Rated Power (kW) | 22 | 22 | |
| Type | Four Stroke, Water Cooling, Spark Ignition, 24V DC Starting | ||
| Displacement (L) | 3.9 | 4.1 | |
| Bore× Stock (mm) | 102*120 | 100*120 | |
| Air Intake Way | Natural | ||
| Rated Speed (r/min) | 1500/1800 (50/60Hz) | ||
| Fuel consumption(m³/Kw·h) | 0.6m³/kw·h | ||
| Alternator | Brand/Model | Faraday | Faraday |
| FD1F | FD1F | ||
| Frequency (Hz) | 50/60 | ||
| Excitation Method | Self-excited, Brushless, AVR | ||
| Phase/Connection | 3 Phase 4 Wire, Y-connection, 0.8 Power Factor (Cosφ) | ||
| Protection Level/Insulation Class | IP23/H | ||
| Control System | The standard control panel is with functions including manual keys, alarms, protections, auto start and shut down, showing running parameters in LCD Display by DEIF SGC420 Controller. | ||
| Options | Special requirements for Container, ATS, Synchronizing Parallel panels and CHP are available for options. | ||
| Dimension (for Open Genset, mm) | 1800*900*1400 | 1620*600*1320 | |
| Weight (KG) | 800 | 620 | |
