INTRODUCTION
| Genset | Genset Model | PLD-200GF | PLD-200GF |
| Rated Power (kW/kVA) | 200/250 | 200/250 | |
| Standby Power (kW/kVA) | 220/275 | 220/275 | |
| Rated Current (A) | 360 | 360 | |
| Manufacturer | Pulita Energy | ||
| Diesel Engine | Main Engine-Body Make | Pekrins | Cummins |
| Diesel Engine Model | 1506A-E88TAG3 | 6LTAA8.9-G2 | |
| Rated Power (kW) | 245 | 220 | |
| Type | Four Stroke, Water Cooling, Direct injection, 24V DC Starting | ||
| Displacement (L) | 8.8 | 8.9 | |
| Bore× Stock (mm) | 112*149 | 114*145 | |
| Air Intake Way | Turbo-charging | Turbo-charging | |
| Rated Speed (r/min) | 1500/1800 (50/60Hz) | ||
| Fuel consumption(L/Kw·h) | 0.21 | ||
| Alternator | Brand/Model | Faraday | |
| FD3H-4 | FD3H-4 | ||
| Frequency (Hz) | 50/60 | ||
| Excitation Method | Self-excited, Brushless, AVR | ||
| Phase/Connection | 3 Phase 4 Wire, Y-connection, 0.8 Power Factor (Cosφ) | ||
| Protection Level/Insulation Class | IP23/H | ||
| Control System | The standard control panel is with functions including manual keys, alarms, protections, auto start and shut down, showing running parameters in LCD Display by DEIF SGC420 Controller. | ||
| Options | Special requirements for Container, ATS, Synchronizing Parallel panels are available for options. | ||
| Dimension (for Open Genset, mm) | 2650*1000*1800 | 2650*1000*1800 | |
| Weight (KG) | 1980 | 1980 | |
