INTRODUCTION
| Genset | Genset Model | PLC-1000GF | PLB-1000GF |
| Rated Power (kW/kVA) | 1000/1250 | 1000/1250 | |
| Standby Power (kW/kVA) | 1100/1375 | 1100/1375 | |
| Rated Current (A) | 1800 | 1800 | |
| Manufacturer | Pulita Energy | ||
| Gas Engine | Main Engine-Body Make | 190 Series | Baudouin |
| Gas Engine Model | H16V190ZLT-2 | 16M33D1280NG10 | |
| Rated Power (kW) | 1250 | 1280 | |
| Type | Four Stroke, Water Cooling, Spare Ignition, 24V DC Starting | ||
| Displacement (L) | 71.4 | 52.5 | |
| Bore× Stock (mm) | 190*210 | 150*185 | |
| Air Intake Way | Turbocharged | Turbocharged | |
| Rated Speed (r/min) | 1500/1800 (50/60Hz) | ||
| Fuel consumption(m³/Kw·h) | 0.3 | ||
| Alternator | Brand/Model | Faraday | Faraday |
| FD6E-4 | FD6E-4 | ||
| Frequency (Hz) | 50/60 | ||
| Excitation Method | Self-excited, Brushless, AVR | ||
| Phase/Connection | 3 Phase 4 Wire, Y-connection, 0.8 Power Factor (Cosφ) | ||
| Protection Level/Insulation Class | IP23/H | ||
| Control System | The standard control panel is with functions including manual keys, alarms, protections, auto start and shut down, showing running parameters in LCD Display by DEIF SGC420 Controller. | ||
| Options | Special requirements for Container, ATS, Synchronizing Parallel panels and CHP are available for options. | ||
| Dimension (for Open Genset, mm) | 5735*2030*2700 | 6090*2200*2700 | |
| Weight (KG) | 18000 | 12300 | |
