INTRODUCTION
| Genset | Genset Model | PLT-50GF | PLTR-50GF |
| Rated Power (kW/kVA) | 50/62.5 | 50/62.5 | |
| Standby Power (kW/kVA) | 55/68.4 | 55/68.4 | |
| Rated Current (A) | 90 | 90 | |
| Manufacturer | Pulita Energy | ||
| Gas Engine | Main Engine-Body Make | Cummins | Ricardo |
| Gas Engine Model | PC6L-BG | HT6105D | |
| Rated Power (kW) | 55 | 55 | |
| Type | Four Stroke, Water Cooling, Spark Ignition, 24V DC Starting | ||
| Displacement (L) | 5.9 | 6.1 | |
| Bore× Stock (mm) | 102*120 | 105*130 | |
| Air Intake Way | Turbocharged | Natural | |
| Rated Speed (r/min) | 1500/1800 (50/60Hz) | 1500/1800 (50/60Hz) | |
| Fuel consumption(m³/Kw·h) | 0.3m³/kw·h | 0.3m³/kw·h | |
| Alternator | Brand/Model | Faraday | Faraday |
| FD2C | FD2C | ||
| Frequency (Hz) | 50/60 | 50/60 | |
| Excitation Method | Self-excited, Brushless, AVR | ||
| Phase/Connection | 3 Phase 4 Wire, Y-connection, 0.8 Power Factor (Cosφ) | ||
| Protection Level/Insulation Class | IP23/H | ||
| Control System | The standard control panel is with functions including manual keys, alarms, protections, auto start and shut down, showing running parameters in LCD Display by DEIF SGC420 Controller. | ||
| Options | Special requirements for Container, ATS, Synchronizing Parallel panels and CHP are available for options. | ||
| Dimension(for Open Genset, mm) | 2200*900*1400 | 2150*740*1480 | |
| Weight (KG) | 1050 | 870 | |
